EKOCable

10 W/m Undertile Heating Cable

EKOCABLE Heating Cables are ready-to-install heating sets. Consisting of a 4mm high temperature resistant cable, this system is designed for indoor use and direct heating. It should be installed directly under the surface to be heated, in either flexible tile adhesive or self levelling compound.

Specification

Type of Heating Cable
Double-core, conductor screen, single-side power supply
Power output10W/m
Power supply230 V ~ 50/60 Hz
External dimension of cable4mm
Min. installation temperature0ºC
Max. working temperature+150ºC
Type of heating cableDouble-core, conductor screen, single-side power supply
InsulationFEP/XLPE
Outer sheathPVC
Min. radius of bending cable5 D
ProtectionIPX8

10 W/m Underfloor heating cable

Part NumberCable Length (m)Power (w)Area (m2)
Concrete Base
Area (m2) Wood
Base
EKO10510.51050.53-0.70.8-1.1
EKO13513.51350.7-0.851.1-1.3
EKO165161650.85-1.051.3-1.7
EKO21020.52101.05-1.351.7-2.1
EKO265272651.35-1.62.1-2.7
EKO315323151.6-2.12.7-3.1
EKO405404052.1-2.43.1-4
EKO48047.54802.4-2.84-4.5
EKO550555502.8-3.64.5-5.5
EKO63563.56353.6-4.15.5-6.3
EKO81581.58154.1-4.76.3-8
EKO935949354.7-6.58-9.8
EKO110011011006.5-7.39.8-11
EKO137013513707.3-911-13.7

Multiple cables can be used for
larger areas

1
2
3
4
5
6
Heating-cable
1

1-2mm Flexible Tile Adhesive

2

Insulation

3

6-8mm Flexible Tile Adhesive

4

Floor Finish

5

Heating Cable

6

Floor Sensor (Inside Conduit)

For more information, please give us a call on 01394 539 109 or email us at mail@ekoheat.co.uk
